Overview:
- Avoid
EPROM "erasing and reprogramming" cycles during development
of ROM based code and data
- Emulates
8 or 16 bit data width (2716, 27C512, 27C800, 27C4096...) up to
8M-Bytes per unit
- Combine
up to four units for 64 bit emulation
- Two proprietary
slots for multiple memory cards and future expansion
- Separate
8 and 8/16 bit target interface connectors
- Both
TTL and CMOS input/output compatible
- No external
power needed (powered by host)
Memory
Card:
- Transportable: allows emulation on remote systems
- Software configurable (switchless)
- Easily expandable by simply adding additional
SRAM
- 3V lithium battery backup
Host:
- High speed data transfer: downloads 1M-byte
in under 2 seconds (hard drive to emulator)
- 8 bit ISA card: compatible with XT, AT, 386,
486 , or higher
Target:
- Access time: approx. 30 ns plus SRAM speed
- Target controlled data width (on 8/16 bit connector)
- I/O lines: 2 (1 RESET) open-collector outputs
and 1 bi-directional
- Target write access to emulation memory or
secondary space using additional memory card
Software:
 View and edit any address range or individual bytes instantly
- Monitor and modify I/O lines
- Download and upload with verify
- Control multiple emulators seamlessly under
one environment with intelligent 16/32/64 bit file splits
- Automatically sets RESET line HIGH, LOW, or
no-action on host access with adjustable delay
- Auto Load feature monitors selected data file for change and automatically
downloads file (Win9x/WinNT version); automatically download file
after source code is compiled locally or over network at remote
location
- Support for Binary, Intel-Hex, and Motorola S-record file formats
